Полоконусные форсунки BK серии

Модель Производительность в л/мин при разном давлении @ 2 BAR Скорость потока (GPH) при различном давлении (psi)
Угол распыления 45° Угол распыления 60° Угол распыления 75° Угол распыления 90° 75 100 125 150 175 200
BK13.0.75 BK14.0.75 BK15.0.75 BK16.0.75 0.03 0.63 0.75 0.79 0.95 0.97 1.10
BK13.1.00 BK14.1.00 BK15.1.00 BK16.1.00 0.03 0.79 1.00 1.10 1.24 1.26 1.42
BK13.1.50 BK14.1.50 BK15.1.50 BK16.1.50 0.05 1.26 1.50 1.74 1.90 1.92 2.06
BK13.2.00 BK14.2.00 BK15.2.00 BK16.2.00 0.07 1.74 2.00 2.21 2.37 2.69 2.85
BK13.2.50 BK14.2.50 BK15.2.50 BK16.2.50 0.09 2.16 2.50 2.80 3.06 3.30 3.54
BK13.3.00 BK14.3.00 BK15.3.00 BK16.3.00 0.1 2.59 3.00 3.35 3.68 3.97 4.25
BK13.3.50 BK14.3.50 BK15.3.50 BK16.3.50 0.12 3.03 3.50 3.91 4.29 4.63 4.95
BK13.4.00 BK14.4.00 BK15.4.00 BK16.4.00 0.13 3.46 4.00 4.47 4.90 5.30 5.66
BK13.4.50 BK14.4.50 BK15.4.50 BK16.4.50 0.15 3.90 4.50 5.04 5.51 5.95 6.36
BK13.5.00 BK14.5.00 BK15.5.00 BK16.5.00 0.17 4.33 5.00 5.59 6.13 6.61 7.07
BK13.5.50 BK14.5.50 BK15.5.50 BK16.5.50 0.18 4.76 5.50 6.15 6.74 7.27 7.78
BK13.6.00 BK14.6.00 BK15.6.00 BK16.6.00 0.2 5.19 6.00 6.71 7.33 7.94 8.48
BK13.6.50 BK14.6.50 BK15.6.50 BK16.6.50 0.22 5.63 6.50 7.26 7.96 8.60 9.20
BK13.7.00 BK14.7.00 BK15.7.00 BK16.7.00 0.24 6.05 7.00 7.82 8.58 9.25 9.90
BK13.7.50 BK14.7.50 BK15.7.50 BK16.7.50 0.25 6.49 7.50 8.38 9.19 9.91 10.60
BK13.8.00 BK14.8.00 BK15.8.00 BK16.8.00 0.27 6.93 8.00 8.94 9.80 10.58 11.31
BK13.8.50 BK14.8.50 BK15.8.50 BK16.8.50 0.29 7.36 8.50 9.50 10.45 11.27 12.08
BK13.9.00 BK14.9.00 BK15.9.00 BK16.9.00 0.3 7.79 9.00 10.06 11.02 11.91 12.73
BK13.9.50 BK14.9.50 BK15.9.50 BK16.9.50 0.32 8.22 9.50 10.60 11.70 12.60 13.50
BK23.10.00 BK24.10.00 BK25.10.00 BK26.10.00 0.34 8.71 10.00 11.09 12.20 13.15 14.10
BK23.10.50 BK24.10.50 BK25.10.50 BK26.10.50 0.36 9.10 10.50 11.70 12.90 13.90 14.90
BK23.12.00 BK24.12.00 BK25.12.00 BK26.12.00 0.4 10.40 12.00 13.40 14.70 15.90 17.00
BK23.13.50 BK24.13.50 BK25.13.50 BK26.13.50 0.46 11.65 13.50 15.07 16.53 17.90 19.17
BK23.15.50 BK24.15.50 BK25.15.50 BK26.15.50 0.55 13.37 15.50 17.33 18.95 20.56 21.89
BK23.17.50 BK24.17.50 BK25.17.50 BK26.17.50 0.6 15.10 17.50 19.60 21.40 23.20 24.80
BK23.19.50 BK24.19.50 BK25.19.50 BK26.19.50 0.65 16.90 19.50 21.80 23.90 25.80 27.60
BK23.21.50 BK24.21.50 BK25.21.50 BK26.21.50 0.7 18.60 21.50 24.00 26.40 28.40 30.40
BK23.24.00 BK24.24.00 BK25.24.00 BK26.24.00 0.8 20.80 24.00 26.80 29.40 31.80 34.00
BK23.28.00 BK24.28.00 BK25.28.00 BK26.28.00 0.9 24.20 28.00 31.30 34.30 37.00 39.60
BK23.30.00 BK24.30.00 BK25.30.00 BK26.30.00 1.0 26.00 30.00 33.60 36.80 39.70 42.50
BK23.35.00 BK24.35.00 BK25.35.00 BK26.35.00 1.2 30.30 35.00 39.10 42.90 46.30 49.50
BK23.40.00 BK24.40.00 BK25.40.00 BK26.40.00 1.3 34.60 40.00 44.70 49.00 53.00 56.50
BK23.45.00 BK24.45.00 BK25.45.00 BK26.45.00 1.5 39.00 45.00 50.40 55.20 59.50 63.70
BK23.50.00 BK24.50.00 BK25.50.00 BK26.50.00 1.7 43.30 50.00 55.90 61.30 66.10 70.70
BK23.55.00 BK24.55.00 BK25.55.00 BK26.55.00 1.8 47.60 55.00 61.50 67.40 72.70 77.70
BK23.60.00 BK24.60.00 BK25.60.00 BK26.60.00 2.0 52.00 60.00 67.00 73.50 79.40 84.00
BK23.70.00 BK24.70.00 BK25.70.00 BK26.70.00 2.4 60.60 70.00 78.20 85.70 92.50 99.00
BK23.80.00 BK24.80.00 BK25.80.00 BK26.80.00 2.7 60.20 80.00 89.40 98.00 106.00 113.50
BK23.90.00 BK24.90.00 BK25.90.00 BK26.90.00 3.0 77.90 90.00 100.90 110.50 119.20 127.50
BK33.100.00 BK34.100.00 BK35.100.00 BK36.100.00 3.4 86.50 100.00 111.90 122.50 132.30 141.40
