Пневматические форсунки DAIA серии
| Соединение | Модель | При давлении 0.7 Bar | При давлении 1.5 Bar | При давлении 2.0 Bar | При давлении 3.0 Bar | При давлении 4.0 Bar | Размер распыления | |||||||||||
| Air (bar) |
l/h | Nm3 h |
Air (bar) |
l/h | Nm3 h |
Air (bar) |
l/h | Nm3 h |
Air (bar) |
l/h | Nm3 h |
Air (bar) |
l/h | Nm3 h |
“C” Эффективная дистанция распыления(mm) |
Max. дистанция распыления (m) |
||
| 1/8 или 1/4 | DAIA 050 | 0.6 | 5.3 | 0.60 | 1.1 | 8.1 | 0.79 | 1.5 | 8.1 | 0.92 | 2.4 | 8.9 | 1.24 | 3.1 | 10.5 | 1.44 | ||
| 0.7 | 4.3 | 0.72 | 1.3 | 7.0 | 0.88 | 1.8 | 6.6 | 1.09 | 2.7 | 8.1 | 1.40 | 3.4 | 9.7 | 1.68 | 230 | 1.5 | ||
| 0.9 | 3.0 | 0.84 | 1.4 | 6.4 | 0.94 | 2.1 | 4.9 | 1.32 | 3.0 | 6.4 | 1.66 | 3.9 | 7.8 | 2.16 | 240 | 1.8 | ||
| 1.0 | 1.7 | 1.02 | 1.5 | 5.5 | 1.01 | 2.4 | 3.2 | 1.68 | 3.2 | 4.9 | 1.92 | 4.2 | 6.1 | 2.52 | 250 | 2.1 | ||
| 1.7 | 4.5 | 1.16 | 3.4 | 4.2 | 2.13 | 4.6 | 4.4 | 2.82 | 260 | 2.7 | ||||||||
| 1.8 | 3.5 | 1.30 | 3.5 | 3.4 | 2.33 | 4.9 | 2.8 | 3.24 | 300 | 4.0 | ||||||||
| 1/8 или 1/4 | DAIA 100 | 0.9 | 7.0 | 3.00 | 1.7 | 13.2 | 4.08 | 2.0 | 18.5 | 4.08 | 2.8 | 25.0 | 5.04 | 3.7 | 31.0 | 5.76 | ||
| 1.0 | 2.1 | 3.72 | 1.8 | 9.8 | 4.74 | 2.1 | 15.1 | 4.56 | 3.0 | 22.0 | 5.52 | 3.8 | 28.0 | 6.30 | 310 | 1.8 | ||
| 2.2 | 11.7 | 5.10 | 3.1 | 18.5 | 6.06 | 3.9 | 26.0 | 6.78 | 330 | 2.4 | ||||||||
| 3.2 | 15.1 | 6.54 | 4.1 | 23.0 | 7.32 | 330 | 3.2 | |||||||||||
| 3.4 | 12.1 | 7.14 | 4.2 | 20.0 | 7.80 | 340 | 4.1 | |||||||||||
| 3.5 | 9.1 | 7.80 | 4.6 | 13.6 | 9.18 | 370 | 5.9 | |||||||||||
| 3.7 | 6.1 | 8.52 | 4.9 | 6.8 | 11.0 | |||||||||||||
| 1/8 или 1/4 | DAIA 150 | 1.1 | 12.3 | 2.40 | 2.2 | 16.3 | 3.72 | 2.7 | 21.0 | 4.14 | 4.2 | 19.3 | 6.00 | 5.6 | 22.0 | 7.80 | ||
| 1.3 | 9.9 | 2.70 | 2.5 | 12.1 | 4.26 | 3.0 | 16.3 | 4.68 | 4.6 | 14.6 | 6.78 | 6.0 | 17.6 | 8.52 | 230 | 2.7 | ||
| 1.4 | 7.9 | 3.00 | 2.8 | 8.9 | 4.74 | 3.2 | 12.3 | 5.16 | 4.9 | 10.8 | 7.44 | 6.3 | 14.0 | 9.12 | 240 | 4.6 | ||
| 1.5 | 6.1 | 3.24 | 3.0 | 7.6 | 4.98 | 3.4 | 10.7 | 5.46 | 5.3 | 8.1 | 8.10 | 6.7 | 11.4 | 9.78 | 240 | 5.5 | ||
| 1.7 | 4.9 | 3.48 | 3.1 | 6.4 | 5.22 | 3.5 | 9.3 | 5.64 | 5.6 | 6.2 | 8.76 | 7.0 | 9.1 | 10.4 | 250 | 7.3 | ||
| 1.8 | 3.9 | 3.72 | 3.2 | 5.5 | 5.46 | 3.9 | 6.4 | 6.30 | 6.0 | 4.9 | 9.42 | 280 | 9.4 | |||||
| 2.0 | 3.1 | 4.02 | 3.4 | 4.7 | 5.70 | 4.2 | 4.7 | 6.90 | 6.3 | 4.0 | 10.00 | |||||||
| 1/8 или 1/4 | DAIA 200 | 0.7 | 24.0 | 1.92 | 1.4 | 43.0 | 2.22 | 2.1 | 33.0 | 3.96 | 2.8 | 52.0 | 3.90 | 3.7 | 63.0 | 4.08 | ||
| 0.9 | 13.6 | 2.64 | 1.5 | 35.0 | 2.94 | 2.2 | 26.0 | 4.68 | 3.0 | 46.0 | 4.56 | 3.8 | 58.0 | 4.74 | 360 | 2.1 | ||
| 1.0 | 7.6 | 3.42 | 1.7 | 28.0 | 3.66 | 2.4 | 18.9 | 5.34 | 3.1 | 39.0 | 5.22 | 4.0 | 52.0 | 6.06 | 370 | 3.2 | ||
| 1.8 | 21.0 | 4.26 | 2.5 | 11.7 | 6.00 | 3.2 | 33.0 | 5.94 | 4.2 | 41.0 | 6.66 | 370 | 4.1 | |||||
| 3.4 | 26.0 | 6.60 | 4.6 | 27.0 | 8.28 | 380 | 5.0 | |||||||||||
| 3.5 | 19.5 | 7.32 | 4.9 | 15.9 | 9.96 | 390 | 6.8 | |||||||||||
| 3.7 | 13.2 | 7.98 | ||||||||||||||||
| 1/8 или 1/4 | DAIA 250 | 1.3 | 36.0 | 5.10 | 2.1 | 57.0 | 6.96 | 3.1 | 53.0 | 9.36 | 4.2 | 64.0 | 11.8 | 5.6 | 74.0 | 14.7 | ||
| 1.5 | 29.0 | 6.12 | 2.4 | 51.0 | 7.80 | 3.2 | 50.0 | 9.78 | 4.9 | 51.0 | 13.8 | 6.0 | 68.0 | 15.6 | 330 | 5.5 | ||
| 1.8 | 23.0 | 7.02 | 2.7 | 45.0 | 8.58 | 3.4 | 47.0 | 10.2 | 5.6 | 40.0 | 15.9 | 6.3 | 62.0 | 16.8 | 340 | 6.4 | ||
| 2.0 | 19.7 | 7.50 | 3.0 | 39.0 | 9.42 | 3.5 | 45.0 | 10.6 | 6.0 | 34.0 | 17.1 | 6.7 | 56.0 | 17.7 | 370 | 8.2 | ||
| 2.1 | 16.7 | 7.98 | 3.2 | 33.0 | 10.2 | 3.9 | 38.0 | 11.6 | 6.3 | 28.0 | 18.0 | 7.0 | 51.0 | 18.9 | 380 | 9.1 | ||
| 2.3 | 14.0 | 8.52 | 3.5 | 28.0 | 11.1 | 4.6 | 25.5 | 13.8 | 6.7 | 22.0 | 19.2 | 400 | 10.4 | |||||
| 2.4 | 11.4 | 8.94 | 4.2 | 13.6 | 13.2 | 4.9 | 18.5 | 14.7 | 7.0 | 17.8 | 20.1 | |||||||
| 1/8 или 1/4 | DAIA 300 | 1.7 | 27.0 | 9.36 | 3.0 | 39.0 | 13.8 | 3.4 | 50.0 | 15.0 | 4.6 | 62.0 | 19.2 | 6.0 | 93.0 | 23.7 | ||
| 1.8 | 20.0 | 10.0 | 3.1 | 33.0 | 14.4 | 3.5 | 43.0 | 15.6 | 4.9 | 47.0 | 20.7 | 6.3 | 77.0 | 25.5 | 460 | 5.5 | ||
| 2.0 | 15.9 | 10.7 | 3.2 | 27.0 | 15.3 | 3.7 | 41.0 | 16.5 | 5.3 | 36.0 | 22.5 | 6.7 | 62.0 | 27.6 | 470 | 6.4 | ||
| 2.1 | 12.5 | 11.6 | 3.4 | 23.0 | 15.9 | 3.9 | 27.0 | 18.0 | 5.6 | 26.0 | 24.3 | 7.0 | 52.0 | 29.7 | 510 | 7.3 | ||
| 2.3 | 10.2 | 12.3 | 3.5 | 18.5 | 16.8 | 4.1 | 23.0 | 18.6 | 6.0 | 18.9 | 26.1 | 530 | 7.9 | |||||
| 7.6 | 3.7 | 14.8 | 17.4 | 4.2 | 18.9 | 19.2 | 6.3 | 13.6 | 27.6 | 580 | 9.8 | |||||||
| 4.4 | 15.9 | 20.1 | ||||||||||||||||
